Dome type equipment capacity 144 core fiber Outdoor Joint Closure Duct Mounting ISO Approved

Outdoor Dome Type Optical Fibre Cable Joint Closure Duct Mounting ISO Approved

1. General

Fiber optic splice

closure is used for protective connection of two or multiple optical cable and optic fiber cable distribution. It is one of commonly used equipment of user access point. Used for the outdoor connection between optical distribution cable and optical in room cable. Available for aerial,duct,direct buried application.

2. Features

A. Up-down bisection, horizontal type
B. 2 inlet/outlet
C. 96 cores max capacity
D. Slide-in-lock design, over 90 opening angle tray
E. Elastic integrated seal ensure tightening fit
F. Housing provide fire resistant, waterproof, and quakeproof for splices while handing
G. Operating Temperature: -40 ~ +65 °C

3. Application

A. Suitable for bunchy fibers

B. Aerial ,wall-mounting

C. FTTH optical fiber distribution

Product description

Introduction

The Dome Fiber Optic Splice Closure is used in aerial, wall-mounting applications, for the straight-through and branching splice of the fiber cable. The closure has five entrance ports on the end (four round ports and one oval port). The shell of the product is made from ABS. The shell and the base are sealed by pressing the silicone rubber with clamp allocated. The entry ports are sealed by heat-shrinkable tube. The closures can be opened again after be sealed, reused again without changing the sealing material.

Technical specifications

PACKAGING & SHIPPING:
