Features
1. Tight buffer fiber ease of stripping.
2. The jacket anti-corrosion, anti-water, anti-alltraviolet ratardation, flame retardant and harmless to environment etc;
3. Excellent flame retardart jacket and anti-torsion;
4. Soft, flexible, easy to splice, and with big capacity data transmission;
5. Excellent performance of anti-torsion;
6. All dielectric structure protect it from electromagnetic influence;
Application
1. Multi optical fiber jumper, patch cord, pigtail cable;
2. Indoor any purpose cable distribution
3. Backbone building distribution cabling.
4. Installation: wall, interlayer, pipe, trough, duct.
Order Optional Information
Jacket material: PVC (Environmental lame-retardant polyvinylchloride), LSZH (Environmental low smoke zero halogen flame retardant polyolefin), or other customerized material.
Jacket color: blue, orange, green, brown, gray, red, black, yellow, and violet, pink, aqua.
Fiber type: B1-G.652, B1.3-G.652.D, B4-G655, A1-50/125μm, A1b-62.5/125μm, M1-Maxband 150, M3-Maxband 300, M5-Maxband 550, E1- EasyBad G.657, E1.1- EasyBad Plus G.657, etc.
Cable Dimension: the nominal cable dimension, or other constomerized dimension;
Fiber Count: total number of fibers in the cable
MOQ: 1km~2km, other customerized
Specificiation
| Fiber count |
Cable Diameter (mm) |
Cable Weight (kg/km) |
Tensile (N)
Long/ Short term
|
Crush (N/100mm)
Long/ Short term
|
Min. Bend Radius (mm)
Dynamic/ Static
|
| 4 |
5.0 |
19.0 |
130/440 |
200/1000 |
20D/10D
|
| 6 |
5.2 |
23.0 |
130/440 |
200/1000 |
| 8 |
5.5 |
26.0 |
130/440 |
200/1000 |
| 12 |
6.5 |
36.5 |
200/660 |
200/1000 |
| 16 |
7.5 |
44.5 |
200/660 |
200/1000 |
| 24 |
8.2 |
54.5 |
200/660 |
200/1000 |
|
Note: 1. The min. bend radius (static) is 5D when G657 fiber is used.
2. Range of temperature: -40~+70°C
3. D is outer diameter of the round cable
4. Tight-buffered fiber is 0.9mm
|
