Figure 8 Self Supporting 12 Core Single Mode FTTH Drop Cable
Product Construction
Fiber:
250µm colorfiber
Fiberglass reinforced plastic (FRP) or Steel Wire.
Self-supported Member:
Steel Wire
Outer Jacket:
UV and Flame resistant LSZH
Features
Compact, soft, flexible, easyto install.
Specifications
Optical Characteristics
|
Fiber Type |
Attenuation |
Overfilled launch Bandwidth |
Effective Modal Bandwidth |
10GB/S Ethernet link length |
Min Bending Radius |
|
|
Conditions |
1310/1550nm |
850/1300nm |
850/1300nm |
850nm |
850nm |
|
|
Unit |
dB/km |
dB/km |
MHZ.km |
MHZ.km |
m |
mm |
|
G652D |
0.36/0.22 |
|
|
|
|
16 |
|
G657A1 |
0.36/0.22 |
|
|
|
|
10 |
|
G657A2 |
0.36/0.22 |
|
|
|
|
7.5 |
|
50/125 |
|
3.0/1.0 |
≥500/500 |
|
|
30 |
|
62.2/125 |
|
3.0/1.0 |
≥200/500 |
|
|
30 |
|
OM3 |
|
3.0/1.0 |
≥1500/500 |
≥2000 |
≥300 |
30 |
|
OM4 |
|
3.0/1.0 |
≥3500/500 |
≥4700 |
≥550 |
30 |
|
B1-OM3 |
|
3.0/1.0 |
≥1500/500 |
≥2000 |
≥300 |
7.5 |
|
B1-OM4 |
|
3.0/1.0 |
≥3500/500 |
≥4700 |
≥550 |
7.5 |
Structure and technical specification
|
Fiber Count |
Cable Diameter (mm) |
Cable Weight (kg/km) |
(N/100mm) |
Crush Resistance (N/100mm) |
||
|
Short Term |
Long Term |
Short Term |
Long Term |
|||
|
1-4 |
5.2*2.0 |
18 |
600 |
300 |
2200 |
1000 |
|
6-12 |
3.0*9.0 |
27 |
1200 |
600 |
1100 |
500 |
Note : This datasheet can only be a reference, but not a supplement to the contract. Please contact the sales for the details.
Packing and Shipping
Cable is supplied in lengths as specified in PI or as requirement. Each length will be shipped on a separate non-returnable wooden drum. The minimum barrel diameter of the drum will not be less than 30 times the cable diameter.
The cable on each reel will be completely covered with a thermal wrap which is fastened to the cable by packaging straps. This wrap is reusable and provides excellent thermal and UV protection.
The cable ends will be sealed with plastic protection caps to prevent water penetration. The ends will be easily accessible for testing. A final inspection test report with attenuation performance data for each fiber is attached inside the drum.
